LOKRING Straight Brass Reducing Connectors Type 00LOKRING NR Ms 00

A metallic component lies on a light grey surface. It is silver in colour and consists of several cylindrical sections separated by narrow rings. One end has a circular opening, while the other end is closed. The surface is smooth and shiny.

For connecting copper and/or steel tubes with different tube outer diameters.

Videos

Technical Data

    • Max. operating pressure: 50 bar (720 psi)
    • Admissible refrigerants: Suitable for all HCs, HFCs and mixtures. Not suitable for NH3.
    • Temperature range: -50°C up to 150°C (-58°F up to 302°F)
    • Tube diameter range: 1.6 to 11 mm (1/16" to 3/8")
    *Solutions for higher operating pressures on request.

      Application

      • Repair of Refrigeration Appliances

      Material Combinations

      >>>Cu-Cu
      >>>Cu-St
      >>>St-St
