Hydraulic Flaring ToolsLOKTOOL HFT

[Translate to English:]

The hydraulic flaring tool is designed for the flaring of aluminium tubes for the production of LOKRING SINGLE RING tube joinings. It is connected to the LOKRING hydraulic aggregate by two 2.8 m hydraulic hoses. The forward and backward movement of the flaring insert is enabled by means of a double acting cylinder. The size of the clamping jaw and the flaring insert depends on the outside tube diameter.

Videos

Technical Data

    • Suitable tube material: Aluminium
    • Max. tube outside diameter: 1/2“ / 12.7 mm*
    • Max. tube wall thickness: 1.0 mm*
    • Operating pressure: up to 300 bar
    • Flaring time: approx. 1 sec.
    • Weight: approx. 1.6 kg
    *Further dimensions on special request.

      Application

      • OEM | Production

      Downloads
