FLUID COUPLING

Power Transmission through hydraulic fluid/water without mechanical connection between input and output of driver or driven machine.

Application

  • Conveyors, Crushers, Shredders, Ball mills, Ring granulators, Mixers, Pumps, Fans, Boiler Feed Pumps, Industrial drives

Efficiency

  • Motor Starting with no load
  • Smooth acceleration of the load
  • Machine and Motor protection against overload, limited to the maximum torque transmitted
  • Motor Selection through the operating torque, avoiding an oversizing selections of the motor by the starting torque
  • Low motor power consumption
  • Excellent ROI (short pay back period)
  • High efficiency due to the low sliding
  • Maximum torque transmission capacity can be achieved in the range of 80 up to 270% of the operating torque
  • Several designs

Tailor-made Solutions

  • Fixed speed
  • Modular design allowing several customization possibilities
  • Radial removability without having to move the connected machinery
  • Possibility of integrating braking discs or pulleys in combination with the coupling
  • Fusible trip device
  • Temperature transmitter (4-20Ma)
  • Variable speed
  • Radial removability without having to move the connected machinery
  • Possibility of integrating braking discs or pulleys within the coupling
  • Temperature transmitter (4-20Ma)
  • Heat exchanger – Shell & tube type Water cooled or Radiator type Air cooled
  • Actuator – Electrical / Pneumatic / Hydraulic with Single & dual speed
  • Control panel
